Colour Blindness

Colourblindness test image 1 Both normal and those with all colour vision deficiencies should read the number 12.
Colourblindness test image 2 Those with normal colour vision should read the number 8. Those with red-green colour vision deficiencies should read the number 3. Total colour blindness should not be able to read any numeral.
Colourblindness test image 3 Normal vision should read the number 29.

Red-green deficiencies should read the number 70.

Total colour blindness should not read any numeral

Colourblindness test image 4 Normal colour vision should read the number 5.

Red-Green colour deficiencies should read the number 2.

Total colour blindness should not be able to read any numeral.

Colourblindness test image 5 Normal colour vision should read the number 3.

Red-Green deficiencies should read the number 5.

Total colour blindness should not be able to read any numeral.

Colourblindness test image 6 Normal colour vision should read the number 15.

Red-Green deficiencies should read the number 17.

Total colour blindness should not be able to read any numeral.

Colourblindness test image 7 Normal colour vision should read the number 74.

Red-Green colour deficiencies should read the number 21.

Total colour blindness should not be able to read any numeral.

Colourblindness test image 8 Normal colour vision should read the number 6.

The majority of those with colour vision deficiencies cannot read this number or will read it incorrectly.

Colourblindness test image 9 Normal colour vision should read the number 45.

The majority of those with colour vision deficiencies cannot read this number or will read it incorrectly.

Colourblindness test image 10 Normal colour vision should read the number 5.

Those with colour vision deficiencies will not read the number or read it incorrectly.

Colourblindness test image 11 Normal colour vision should read the number 7.

Those with colour vision deficiencies will not read this number or read it incorrectly.

Colourblindness test image 12 Normal colour vision should read the number 16.

Those with colour vision deficiencies will not read this number or read it incorrectly.

Colourblindness test image 13 Normal colour vision will read the number 73.

Those with colour vision deficiencies should nor be able to read this number or will read it incorrectly.

Colourblindness test image 14 Normal colour vision and those with total colour blindness should not be able to read any number.

The majority of those with red-green deficiencies should read the number 5.

Colourblindness test image 15 Normal colour vision and those with total colour blindness should not be able to read any number.

The majority of those with red-green deficiencies should read the number 45.

Colourblindness test image 16 Normal colour vision should read the number 26.

In protanopia and strong protanomalia the number 6 is read and in mild protanomalia both numerals are read but the number 6 is clearer than the number 2.

In deuteranopia and strong deuteranomalia only the number 2 is read and in mild deuteranomalia both the number 2 is clearer than the number 6.

Colourblindness test image 17 Normal colour vision should read the number 42.

In protanopia and strong protanomalia the number 2 is read and in mild protanomalia both numerals are read but the number 2 is clearer than the number 4.

In deuteranopia and strong deuteranomalia only the number 4 is read and in mild deuteranomalia both the number 4 is clearer than the number 2.

Colourblindness test image 18 The normal should trace along the purple and red lines between the two X's.

In protanopia and strong protanomalia only the purple line is traced and in mild protanomalia both lines can be traced but the purple line is easier to follow.

In deuteranopia and strong deuteranomalia only the red line is traced and in mild deuteranomalia both lines are traced but the red line is easier to follow.

Colourblindness test image 19 The majority of those with red-green colour blindness can trace the winding line between the two X's.

The majority of those with normal and total colour blindness are unable to follow the line.

Colourblindness test image 20 Normal will trace the blue-green line between the two X's.

The majority of those with colour vision deficiencies will be unable to follow the line or will follow a line different to the normal one.

Colourblindness test image 21 Normal will trace the orange line between the two X's.

The majority of those with colour vision deficiencies will be unable to follow the line or will follow a line different to the normal one.

Colourblindness test image 22 Normal should trace the line connecting the blue-green and the yellow-green.

Those with red-green deficiencies trace the line connecting the blue-green and purple.

Those with total colour blindness cannot trace any line.

Colourblindness test image 23 Normal should trace the line connecting the purple and the orange between the two X's.

Red-green deficiencies should trace the line connecting the purple and the blue-green.

Total colour blindness and weakness cannot trace any line.

Colourblindness test image 24 Both normal and those with colour vision deficiencies can trace the winding line between the two X's.
